Well, after having attended TechEd last week and the Microsoft Management Summit in April it’s clear that virtualization, managed via the private cloud needs to be a critical part of a messaging administrator’s proficiencies. In this post I’m going to summarize some of the best practices when virtualizing your Exchange servers in a Hyper-V environment as referenced in a recent whitepaper released by Microsoft.

Scale-Up or Out?

The whitepaper generally recommends that organizations scale up (fewer server, more resources each) rather than out although both options are supported as it largely depends upon the customer’s environment.

Hyper-V Root Sizing

• For RAM calculations add an additional GB of RAM for Windows Server 2008 R2 management
• Dedicated management NIC for the Hyper-V root Server
• When using live migration dedicate a GB NIC
• Separate dedicated NICs for ISCSI
• Separate LUNs/Arrays for Management OS, Guest OS and VM storage
• RAID for data protection
• Blades with two local disks, host only. Guests on DAS or SAN
• BIN file planning, equal to the memory allocated for each VM, stored with the guest VHD
• 10% CPU overhead for hypervisor management of guests

Hyper-V Guest Configuration

Memory

• Sized according to physical deployments
• Disable dynamic memory adjustment

Storage

• Fixed VHD’s for the virtual OS
• Separate spindles for Exchange from guest OS
• Hub Transport, consider space for message queue database and logs
• Mailbox Role, consider databases, transaction logs, content index and other logs.

Determining Exchange Server Role VM locations

• Deploy the same roles across multiple physical server roots for HA and load balancing
• Do not deploy members of the same DAG or all CAS or HUB on the same root (defeats HA)
• Balance workload  across guest VM’s
• Deployment Recommendations
• Design guest VMs according to standard Exchange 2010 deployment principles
• Balance all roles among the root servers in order to maximize physical resources

This is just a quick summary of some of the basic items to take into considering when virtualizing Exchange 2010 with Hyper-V. For full details I recommend reading the entire paper (39 Pages) which can be downloaded here.
